Standard pharmacopoeia sieve

  • Category:Test sieve
  • Description:Pharmacopoeia sieve is unified specifications stainless steel sieve used for Pharmaceutical production.It is used for screening liquid, powder, solid particles is pharmaceutical companies.
  • Features
Pharmacopoeia sieve overview
China pharmacopoeia stipulate No.1-9 is pharmacopoeia standard sieve, No.1 is the biggest mesh, meshes are 10 mesh, 24 mesh, 50 mesh, 65 mesh, 80 mesh, 100 mesh, 120 mesh, 150 mesh and 200 mesh. It is used for liquid, powder, solid particles screening in pharmaceutical companies. It is used for screening liquid, powder, solid particles in pharmaceutical companies. Pharmacopoeia sieve can be screening by hands.  In order to improve the efficiency, it also can be used with the test sieve machine or slap vibrating sieve machine together.

Pharmacopoeia sieve model
Sieve diameter and height are standard 200 mm*50 mm

Name Sieve number Mesh Mesh size(μm) The mesh tolerance
Pharmacopoeia sieve S-1 10 2000 ±70μm
Pharmacopoeia sieve S-2 24 850 ±29μm
Pharmacopoeia sieve S-3 50 355 ±13μm
Pharmacopoeia sieve S-4 65 250 ±9.9μm
Pharmacopoeia sieve S-5 80 180 ±7.6μm
Pharmacopoeia sieve S-6 100 150 ±6.6μm
Pharmacopoeia sieve S-7 120 125 ±5.8μm
Pharmacopoeia sieve S-8 150 90 ±4.6μm
Pharmacopoeia sieve S-9 200 75 ±4.1μm
Standard pharmacopoeia sieve features
1. Strong and durable
2. Double package edge design, there is no steel cross section, no burr, it won't scratch hand, complying with the requirement of safe operation.
3. Sieve box adopts SUS304 stainless steel material, conform to the requirements of the health, food and pharmaceutical industry.
4. Screen is made of stainless steel woven, aperture conform to GB6003.1-2012 standard. After strict inspection, product will be shipped form factory.

Certification:

How to purchase our machine:

You can contact me through these ways to get all information of the machine.
Becky Yang
E-mail:dhsales01@xxdahan.com
Skype:y1.becky
WhatsApp:0086-18738378118
Wechat: xxdhzds111
Xinxiang Dahan vibrating machinery Co.,Ltd
http://cndahan.en.alibaba.com/productlist.html
Address:1000 West of Forest Park,Yanjin County,Xinxiang City,Henan Province,China.
If you place a order,we will arrange the delivery in 3 workingdays after receiving your payment!
